The AP -530 is a bright new concept in low cost, single door, stand alone access control. The AP-530 provides time zone control of access with its battery-backed real time clock, and provides a printer output for event logging and configuring, via its RS-232 Serial interface. No programming cards, as used on other low cost stand-alone readers, are required. All AP-530 programming is performed via 12 position keypad

Wide output voltage range (+6 to +24 VDC)

Small, rugged/surface mount/ 1 million pass read head

Mounts with security screw/tamper switch

3 LEDs access and reader status

Low Power / surface mount/1 million pass read head

Complete array of coordinated mounting hardware

Attractive, weatherised finishes

12 position keypad with audible feedback
Real Time clock with battery back-up

RS_232 printer interface/Bi-directional swipe

1000 sequential /100 random or credit cards

4 time zones/7 access levels/20 Holidays

Moniters and reports reader tamper/door alarm

Output for door srike / output for auxiliary use

Non-volatile memeory for card/PIN storage

Installs with plug-in connectors
